Brand
ATOM

Model
HSP 588/10

Type
Presses, Die Cutting

Stock #
32093

Condition
Used

Year

Location
Cincinnati, Ohio
United States

Request Quote

Specifications

Equipped With

ATOM HYDRAULIC CLICKER PRESS

MODEL: HSP 588/10
SERIAL NUMBER: 960822B020607

GENERAL SPECIFICATIONS

"Hydraulic die-cutting machine that is designed for cutting materials like rubber, foam, paper or plastic."

Traveling Head
Maximum Cutting Force: 30 Tons
Cutting Stroke: 0 - 6"
Cutting Table: 82-5/8" x 29-1/2"
Cutting Head: 29-1/4" x 29-1/4"
Daylight Opening: 7" Maximum
Floor To Top Of Bed: 37-1/2"

EQUIPPED WITH

2 HP Hydraulic Motor
1 HP Trolley Motor
Dual Operator Pushbutton Operation
Stroke and Pressure Control

Approximate Weight: 3000 Lbs.

F.O.B. Cincinnati, Ohio

ALL SPECIFICATIONS SUBJECT TO VERIFICATION BY PURCHASER
